OMS240
OMS240
Description
The
LP3996 is a low-dropout voltage regulator with low
quiescent
current and in ultra-small package. The LP3996 can
deliver output current up to 250mA. It offers different
output
voltage within 0.7V to 5.2V. The
LP3996 is integrated over current protection and short
circuit
protection in order to protect system abnormal. The
output capacitor as small as 0.1µF is good enough for
LP3996.The
LP3996 is available in 4 pins ultra-small DFN package
with only
1mm 1mm
size.
Features
⚫Ultra-low
current consumption: 0.7µA (Typ)
⚫Wide
input voltage range: 1.5V to 5.5V
⚫Fixed
output voltages: −0.7V
to 5.2V with 100mV/step
⚫High
output voltage accuracy: ±1.5%
⚫Low
dropout voltage: −60mV
(Typ) at 50mA (VOUT=
3.3V) −130mV
(Typ) at 100mA (VOUT=
3.3V)
⚫Integrated
over-current protection
⚫Support
1.8V logic EN pin
⚫Robust
ESD capability: −Human
Body Model: 2 kV −Charged
Device Model: 0.5 kV
⚫Available
in small packages: −TDFN-4L,
1.0mm 1.0mm
Applications
⚫Wearable
Devices
⚫Portable
Medical Equipment
⚫PDAs,
Mobile Phones GPS devices
